Cloud migration: 5 strategies for migrating your applications to the cloud

5 cloud migration strategies blog image

Understand the pros and cons of your cloud migration options – Lift-and-Shift; Lift, Shift, & Optimize; Refactoring; Containers; and Full Rebuild

You’ve decided that migrating one or more applications to the cloud is necessary, and you’ve received the go-ahead from management to do so.

So what approaches can you now take to execute your migration?

You have five primary options you can choose to migrate your applications to the cloud:

  1. The Lift-and-Shift Approach
  2. Lift, Shift, and Optimize
  3. Refactoring your app
  4. Containers
  5. Full rebuild of your app

The option you select will depend a lot on your specific situation. Questions to ask yourself include:

  • How much knowledge and experience do you have with cloud migrations?
  • What level of resources can you dedicate to migrating your app(s)?
  • How quickly do you need to migrate to the cloud?
  • How much risk are you willing to take?

Once you answer these questions, you can make an informed decision on which option works best for your company at this time.

Let’s dig deeper into the approaches you can use to migrate to the cloud.

5 cloud migration strategies blog image

1) Lift-and-Shift Approach

The first way to migrate to the cloud is by using the “Lift-and-Shift” (L&S) approach.

This is pretty much what it sounds like – lifting a portion of or an entire existing application from your on-premise infrastructure and shifting it to the cloud with few or no modifications to the underlying code.

It’s a great way to get started with moving to the cloud, as there will be minimal disruption to the application you’re migrating.

Additionally, the L&S model is a very good option for cloud disaster recovery, where you can leverage the cloud to backup your data without changing the application’s architecture.

GE Oil and Gas used the Lift-and-Shift model to kick off their migration of over 500 applications to AWS in two years and saw cost savings of 30% without optimizations.

As you can see, the L&S approach can still have a significant impact on your company even if it is the simplest option.

Pros of Lift-and-Shift

The L&S approach is a great starting point in moving to the cloud. It’s the least costly and time-intensive method, and your team will obtain a wealth of valuable knowledge for larger, more complex cloud migrations in the future.

Lift-and-Shift is also an effective way to immediately reduce high on-premise infrastructure costs in the short term, just like GE Oil and Gas did.

There will be times where making code changes is impossible, such as if you’re looking to run off-the-shelf software in the cloud. In these cases, the Lift-and-Shift approach may be your only option.

Finally, sometimes applications can be easier to optimize once they are in the cloud, so lifting and shifting may be the best option to get that application into the cloud quickly.

Cons of Lift-and-Shift

The primary con of the Lift-and-Shift approach is that you won’t be able to leverage the full power of the cloud. Because your application wasn’t designed and built with the cloud in mind, it won’t be optimized to take advantage of the speed, agility, and scalability that the cloud has to offer.

Additionally, because your application isn’t optimized for the cloud, it might consume more cloud resources than necessary. This could increase your cloud costs in the long term.

Regardless, the Lift-and-Shift approach is a great way to get your cloud migration journey started.

2) Lift, Shift, and Optimize

The Lift, Shift, and Optimize (LSO) approach is when you replicate your current application in the cloud but make minor tweaks and optimizations to improve your app.

The LSO approach can be used when it’s clear that there are minor optimizations that can be made that won’t break your application. Otherwise, you may have to perform a full refactor (which we’ll talk about more in the next section), which is a much more involved process.

An example of LSO is Sprint’s migration of their SMS messaging platform from on-premise to the cloud, which we helped with.

The platform, which delivers over 3 million text messages per day, was complicated and had many components to it. And the company needed to continue to use the software while the cloud migration was occurring.

So we believed that we could lift and shift many parts of the application to the cloud, then optimize once the platform was stable. And we continue to make improvements with ongoing optimizations to data warehouses, load balancing, and more.

Pros of Lift, Shift, and Optimize

With the LSO model, you’ll reap more of the benefits of the cloud than if you were to just lift-and-shift your app, and it’s much faster and easier than a full refactoring.

For example, in addition to moving your application from on-premise servers to Amazon EC2, you may also decide to move your data over to Amazon Aurora or RDS to lower the time and money you spend managing databases. This additional step won’t significantly impact your application but will help you garner additional perks of the cloud.

Cons of Lift, Shift, and Optimize

The only con of the LSO approach is that your application isn’t fully optimized for the cloud, so you’re not taking advantage of everything the cloud has to offer.

Your company may not realize all of the cost savings and enhancements to agility and flexibility that the cloud provides.

Overall, the LSO approach falls right into the sweet spot between a traditional Lift-and-Shift and a full refactoring, which is a pretty good place to be.

[thrive_leads id=’8366′]



3) Refactoring

A refactoring entails making major changes to your application’s code or configuration in order to move it to the cloud without impacting its external behavior.

There can be a couple of reasons for a refactoring:

  1. The application, in its current state, is not fit to be run in the cloud. So you have to make significant code revisions in order to migrate it and have the app work properly.
  2. There is a strong need to add features, improve performance, or scale the application once in the cloud, and these improvements cannot be achieved in the application’s existing state.

Refactoring can be a big endeavor, so you’ll need to be sure that you have enough resources and time to do it right.

Pros of Refactoring

When you refactor your app to migrate to the cloud, you can structure your code to take full advantage of everything the cloud has to offer. This will result in an app that is faster, more reliable, and more scalable.

For instance, your old app may be hampered by a slow way of ingesting real-time data. If you choose to move to AWS, you can refactor your code to efficiently leverage Amazon Kinesis to more quickly process this data.

Also, you can optimize your app to lower long-term cloud costs. When you refactor your app, you can design it so that it uses cloud compute, storage, database, and other resources more efficiently, which can significantly cut down on your costs over time.

Cons of Refactoring

To achieve the speed, reliability, and lower long-term cost of a cloud application, you’ll have to perform more work upfront to refactor your app.

This can be very costly in the near-term, since you’ll have to deploy additional engineers and other staff to get your app ready for the cloud.

You’ll also assume a much higher level of risk compared to the more straightforward Lift-and-Shift and Lift, Shift, and Optimize options.

Finally, because of all of the work you need to put into changing your application’s code, much more time will elapse until you can deploy your new app.

While the refactoring approach will benefit you in the long term, you should thoroughly understand your short-term tradeoffs to decide if it’s the right choice for your company.

Cloud migration approaches pros and cons
Summary of pros and cons for each cloud migration strategy

4) Containers

Another way to move to the cloud is by using containers.

Containers are an increasingly popular and exciting technology that allows you to run software reliably when moved from one computing environment (such as your on-premise servers) to another (such as a cloud environment) without requiring code changes.

Containers achieve this by bundling the components necessary – the application, libraries, dependencies, binaries, and configuration files – for the app to run, and nothing more. The container is abstracted away from the operating system and the physical infrastructure so it can be easily and reliably ported to different computing environments.

Docker is currently the most popular container management platform, while CoreOS and Kubernetes are also frequently used by the DevOps community.

Some of the largest web properties in the world like Spotify, Zulily, and Bleacher Report use containers to scale their applications in the cloud.

Pros of Containers

The first pro of containers is their portability between different computing environments. Whether you want to move your application from a local to production environment, from on-premise to the cloud, or from one cloud provider to another, containers can help you do so easily and quickly.

Provisioning containers takes only a few seconds, which makes them almost immediately scalable. If usage of your application increases, more containers can be provisioned to handle this load increase. Then these containers can be destroyed if demand subsides.

The average size of a container is in the tens of megabytes, while virtual machines can be several gigabytes. Thus, running containers is less resource intensive and can cut down your costs.

The use of containers can significantly reduce development and testing time, since the developer doesn’t have to worry about deploying to multiple environments anymore.

Containers also provide an unprecedented level of flexibility in distributed computing. Because containers allow you to compartmentalize applications, you can feasibly distribute your app across multiple computing environments to optimize for cost and performance.

For example, if one portion of your application requires the highest level of security for compliance reasons, you can have one container running in a private cloud. If another portion demands high compute resources, you can put that on the public cloud to leverage load balancing and scaling. Then you can even run the remaining portion on-premise or in any other environment of your choice.

Cons of Containers

The first disadvantage of containers, compared to traditional virtual machines, is security.

Because containers are abstracted away from the operating system, they need to share the kernel and other components of the host OS. Thus, if there is an intrusion of the kernel, every container that shares it is susceptible to a breach.

Containers can also be less flexible if you’re dealing with complex enterprise apps that run on multiple operating systems. With traditional virtual machines, you can run multiple OSs, like Linux and Windows, on the same server. On the other hand, you need to provision a new server to be able to run containers with different OSs.

Another potential drawback of containers is the additional management needed to keep track of all of them. Because they can be provisioned so quickly and simply, “container sprawl” can easily occur and you may find yourself using more compute resources and paying more than necessary. While tools from Docker and CoreOS are improving, the management of containers is still much more difficult than that of virtual machines.

While the technology has been around for awhile, containers have become very popular in their newest incarnation, and they might be a great cloud migration solution for your company.

5) Full Rebuild

The final option you have to move to the cloud is to rebuild your application from the ground up and make it fully cloud-native – that is, designed and developed to take full advantage of the benefits of cloud computing.

The primary reason to select this approach is that your application is just too old and outdated to spend any more time maintaining it, and the value you get out of rebuilding it exceeds that of sustaining it.

Pros of a Full Rebuild

When you completely rebuild an application, you can develop it to fully leverage everything the cloud has to offer. Moreover, you won’t inherit any of the problems that already exist in the application, as might be the case with a refactoring.

And you may save even more in long-term costs because everything about the app can be fully optimized to use cloud resources more efficiently.

With a complete rebuild, the sky’s the limit (pun intended) on how you can reap all the benefits of cloud computing.

Cons of a Full Rebuild

There is significant risk in completely rebuilding an application, even more so than a refactoring.

First of all, you’ll have to deploy a full team of engineers, product and project managers, and many other resources to get the new application off the ground. This could cost a lot of money.

And you’ll need a thorough understanding of how to build the application to be cloud-native.

Because of all this, it will take even more time to get your new app to market.

With a full rebuild, you can reap all of the long-term benefits of moving to the cloud, but there is certainly a high amount of risk in the short term.

Conclusion

There isn’t one best solution for moving your applications to the cloud.

Each approach has its pros and cons, and risks and rewards.

You may find yourself employing more than one of these options if you move multiple applications to the cloud.

Understanding the priorities and situations of your company and applications will help you determine whether Lift-and-Shift, Lift, Shift & Optimize, refactoring, containers, or full rebuild is the best approach.

What are your thoughts on these cloud migration options? Have you used one or more of them, and how did it work out? We’d love to hear your thoughts in the comments.
